DMX512/1990 standard, 384 DMX control channels, optically isolated signal output.

Simultaneously control 30 computer lights, with 32 control channels per light, using dynamic light address settings.

50 built-in Shape Trajectory Generator (SHAPE), convenient for users to control the graphic trajectory of computer lights, with various effects such as picture circles, gradient circles, lines, words, waves, etc. Graphic parameters such as speed, size, expansion, and orientation can be independently set.

A walking light program with multiple steps per program, optional automatic speed control, intelligent manual beat control (SWING), or music synchronization control.

It can simultaneously run 2 lighting programs, 30 preset scenarios, and perform lighting operations on 30 computer lights.

Equipped with a flash card slot, users can use the flash card to save their valuable data (flash card purchased separately).

Backlit LCD displays operating parameters.

Shutdown data retention.

Power supply: AC100-240V/50-60Hz high-performance green switching power supply.

Equipment volume/net weight: 485mm x 267mm x 85mm/5.1kg

Packaging volume/gross weight: 600mm x 370mm x 210mm/7.6kg
